Android開發:仿微信圖片選擇器

編輯:關於Android編程

Android 仿微信 圖片選擇器采用項目的框架上采用mvp模式,並用了我自己寫的一套lib,地址ndileber
首先先定義了數據源,數據源可能來自於網絡也可能來自於本地,於是我定義了兩個數據源,分別處理網絡和本地的數據:
我先創建了數據源接口:
ImageDataSource

public interface ImageDataSource extends BaseDataSource{

    void getAllImage(BaseCallback> callback);

}

建立model,model建立的原因是我要反向將數據注入到這裡

public class ImageModel {

     Integer _id;

     String _display_name;
     String _data;
    private boolean check = false;

    public boolean isCheck() {
        return check;
    }

    public void setCheck(boolean check) {
        this.check = check;
    }

    public Integer get_id() {
        return _id;
    }

    public void set_id(Integer _id) {
        this._id = _id;
    }

    public String get_display_name() {
        return _display_name;
    }

    public void set_display_name(String _display_name) {
        this._display_name = _display_name;
    }

    public String get_data() {
        return _data;
    }

    public void set_data(String _data) {
        this._data = _data;
    }
}

網絡數據源:當然目前僅僅是測試本地數據源,於是網絡數據源只是簡單的實現了ImageDataSource 方法
ImageRemoteDataSource

public class ImageRemoteDataSource extends BaseRemoteDataSource implements ImageDataSource {

    private static volatile ImageRemoteDataSource instance;

    private ImageRemoteDataSource(){
    }

    public static ImageRemoteDataSource getInstance(){
        if (instance==null){
            synchronized (ImageRemoteDataSource.class){
                if(instance==null){
                    instance = new ImageRemoteDataSource();
                }
            }
        }
        return instance;
    }

    @Override
    public void getAllImage(BaseCallback> callback) {

    }
}

本地數據源:數據源來自於Provider,lib中將Provider封裝了,直接可以調取數據並且按照時間來排序
ImageLocalDataSource

public class ImageLocalDataSource extends BaseLocalDataSource implements ImageDataSource {

    private static volatile ImageLocalDataSource instance;

    private ImageLocalDataSource(){
    }

    public static ImageLocalDataSource getInstance(){
        if (instance==null){
            synchronized (ImageLocalDataSource.class){
                if(instance==null){
                    instance = new ImageLocalDataSource();
                }
            }
        }
        return instance;
    }

    @Override
    public void getAllImage(final BaseCallback> callback) {

        ThreadExecutor.getInstance().submit(new Runnable() {
            @Override
            public void run() {
                Logger.d("進入getAllImage");
                String[] projection = { MediaStore.Images.Media._ID, MediaStore.Images.Media.DISPLAY_NAME,MediaStore.Images.Media.DATA };
                String orderBy = android.provider.ContactsContract.Contacts._ID + " DESC";
                Uri uri = MediaStore.Images.Media.EXTERNAL_CONTENT_URI;
                List imageModels = null;
                try {
                    imageModels = hContentProvider.query(projection,orderBy,uri,ImageModel.class);
                } catch (IllegalAccessException e) {
                    e.printStackTrace();
                } catch (InstantiationException e) {
                    e.printStackTrace();
                } catch (NoSuchFieldException e) {
                    e.printStackTrace();
                }
                callback.onSuccess(imageModels);
            }
        });

    }



}

之後建立數據倉庫類

public class ImagesRepository extends BaseRepository implements ImageDataSource{

    List url;

    private static volatile ImagesRepository instance;

    public static ImagesRepository getInstance(){
        if (instance==null){
            synchronized (ImagesRepository.class){
                if(instance==null){
                    instance = new ImagesRepository(ImageLocalDataSource.getInstance(),ImageRemoteDataSource.getInstance());
                }
            }
        }
        return instance;
    }

    protected ImagesRepository(ImageLocalDataSource localDataSource, ImageRemoteDataSource remoteDataSource) {
        super(localDataSource, remoteDataSource);
    }

    @Override
    public void getAllImage(BaseCallback> callback) {
        localDataSource.getAllImage(callback);
    }

}

寫法是采用在activity中包fragment的方法
之後我們建立了activity的layout





    <framelayout android:id="@+id/images_framelayout" android:layout_alignparenttop="true" android:layout_centerhorizontal="true" android:layout_height="match_parent" android:layout_width="match_parent"></framelayout>

再建立fragment的layout,一如既往的采用RecyclerView

<framelayout android:layout_height="match_parent" android:layout_width="match_parent" tools:context="com.jcb.www.jcbmanager.fragment.ImagesFragment" xmlns:android="http://schemas.android.com/apk/res/android" xmlns:tools="http://schemas.android.com/tools">




</framelayout>

之後建立我們需要的cell圖像采用 SimpleDraweeView























資料圖
圖片描述
圖片描述

activity代碼如下 (最近lib進行了更改,這塊代碼還沒改掉)<喎?/kf/ware/vc/" target="_blank" class="keylink">vcD4NCjxwcmUgY2xhc3M9"brush:java;"> public class ImagesActivity extends BaseActivity implements ImagesFragment.OnFragmentInteractionListener{ @Override protected void onCreate(Bundle savedInstanceState) { super.onCreate(savedInstanceState); setContentView(R.layout.activity_images); ActivityUtils.getFragment(getSupportFragmentManager(),R.id.images_framelayout, ImagesFragment.newInstance()); } }

創建adapter

public class ImagesRecyclerAdapter extends RecyclerView.Adapter{

    private List urls;

    private ImagesFragment.OnFragmentInteractionListener interactionListener;

    public ImagesRecyclerAdapter(List urls,ImagesFragment.OnFragmentInteractionListener interactionListener){
        this.urls = urls;
        this.interactionListener = interactionListener;
    }


    @Override
    public ImageViewHoder onCreateViewHolder(ViewGroup parent, int viewType) {
        View view = LayoutInflater.from(parent.getContext()).inflate(R.layout.images_image,parent,false);
        return new ImageViewHoder(view);
    }

    @Override
    public void onBindViewHolder(final ImageViewHoder holder, int position) {
        holder.url = urls.get(position);
        UImage.showThumb(Uri.fromFile(new File(holder.url.get_data())), holder.imageView,200,200);
        setImage(holder.check,R.drawable.jy_checkbox_off);
        if(holder.url.isCheck()){
            setImage(holder.check,R.drawable.jy_checkbox_on);
        }else{
            setImage(holder.check,R.drawable.jy_checkbox_off);
        }
        holder.item.setOnClickListener(new View.OnClickListener() {
            @Override
            public void onClick(View v) {
                Intent it = new Intent();
                it.setClass(ActivityManager.peekTopActivity(), BigImageActivity.class);
                it.putExtra(BigImageActivity.UTI,holder.url.get_data());
                ActivityManager.peekTopActivity().startActivity(it);
            }
        });
        holder.check.setOnClickListener(new View.OnClickListener() {
            @Override
            public void onClick(View v) {
                ImageView check = (ImageView)v;
                if(holder.url.isCheck()){
                    setImage(check,R.drawable.jy_checkbox_off);
                    holder.url.setCheck(false);
                }else{
                    setImage(check,R.drawable.jy_checkbox_on);
                    holder.url.setCheck(true);
                }

            }
        });
    }

    public void setImage(ImageView check,int res){
        if (Build.VERSION.SDK_INT >= Build.VERSION_CODES.LOLLIPOP) {
            check.setBackground(ActivityManager.peekTopActivity().getResources().getDrawable(res,ActivityManager.peekTopActivity().getTheme()));
        }else{
            check.setBackground(ActivityManager.peekTopActivity().getResources().getDrawable(res));
        }
    }

    @Override
    public int getItemCount() {
        if(urls==null){
            return 0;
        }
        return urls.size();
    }

    class ImageViewHoder extends RecyclerView.ViewHolder{

        private final SimpleDraweeView imageView;
        private final ImageView check;
        private final View item;
        private ImageModel url;

        public ImageViewHoder(View itemView) {
            super(itemView);
            this.item = itemView;
            imageView = (SimpleDraweeView) itemView.findViewById(R.id.iamges_im);
            check = (ImageView) itemView.findViewById(R.id.image_check);

        }
    }

}

fragment代碼如下,主要是調用數據源數據進行顯示的

public class ImagesFragment extends BaseFragment {

    private OnFragmentInteractionListener mListener;

    public ImagesFragment() {
    }


    public static ImagesFragment newInstance() {
        ImagesFragment fragment = new ImagesFragment();
        return fragment;
    }

    @Override
    public void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
    }

    RecyclerView recyclerView;

    @Override
    public View onCreateView(LayoutInflater inflater, ViewGroup container,
                             Bundle savedInstanceState) {
        View view = inflater.inflate(R.layout.fragment_images, container, false);
        Context context = view.getContext();
        recyclerView = getView(view,R.id.images_Recycler);
        recyclerView.setLayoutManager(new GridLayoutManager(context,3));
        Logger.d("進入imagesfragemt");
        ImagesRepository.getInstance().getAllImage(new BaseDataSource.BaseCallback>() {
            @Override
            public void onSuccess(final List imageModels) {
                //Logger.d(imageModels.size()+ HJson.toJson(imageModels));
                getActivity().runOnUiThread(new Runnable() {
                    @Override
                    public void run() {
                        recyclerView.setAdapter(new ImagesRecyclerAdapter(imageModels,mListener));
                    }
                });
            }

            @Override
            public void onFailure(DataSourceException e) {

            }
        });

        return view;
    }

    @Override
    public void onAttach(Context context) {
        super.onAttach(context);
        if (context instanceof OnFragmentInteractionListener) {
            mListener = (OnFragmentInteractionListener) context;
        } else {
            throw new RuntimeException(context.toString()
                    + " must implement OnFragmentInteractionListener");
        }
    }

    @Override
    public void onDetach() {
        super.onDetach();
        mListener = null;
    }

}

其實到這裡代碼還是沒寫完呢,只是展示了圖片,代碼後續部分,大家就自行完成好了,如果我有心情的話我會把我仿照微信的整套代碼全部貼出到github上,如有什麼建議或者意見請在下面評論,我會偶爾看的
