編輯:關於Android編程
Android的窗口體系中,WindowManager占有非常重要的地位,它封裝了添加、移除、更新窗口的方法,它是Activity、View的更加底層的管理類,使用WindowManager的其中一個例子就是制作懸浮窗或懸浮球之類的懸浮組件,這種懸浮組件不依賴某個Activity,它可以在任何界面顯示(只要你願意)。
這篇文章將對如何使用懸浮球做簡單總結,即使在android6.0下(android6.0使用動態權限管理),它也可以正常工作。ButterKnife可以方便的獲取到xml中定義的view的實例,比findViewById方便多了,使用ButterKnife非常簡單,可以總結為3步吧:
compile 'com.jakewharton:butterknife:7.0.0'
@Bind(R.id.start) Button start; @Bind(R.id.stop) Button stop; @Bind(R.id.bind) Button bind; @Bind(R.id.unbind) Button unbind;
ButterKnife.bind(this);在onCreate中調用它就可以。通過這句調用,start,stop,bind,unbind幾個Button都被實例化了。
public class FlowWindowService extends Service { private final String TAG = "FlowWindowService"; @Override public void onCreate() { super.onCreate(); Log.d(TAG,"onCreate"); } @Nullable @Override public IBinder onBind(Intent intent) { Log.d(TAG,"onBind"); return null; } @Override public int onStartCommand(Intent intent, int flags, int startId) { Log.d(TAG,"onStartCommand"); showFlowWindow(); return super.onStartCommand(intent, flags, startId); } @Override public void onDestroy() { super.onDestroy(); Log.d(TAG,"onDestroy"); } public void showFlowWindow(){ Log.v(TAG,"showFlowWindow"); WindowManager windowManager = (WindowManager) getSystemService(WINDOW_SERVICE); Button button = new Button(getApplicationContext()); button.setText("flow"); button.setBackgroundColor(Color.RED); button.setWidth(100); button.setHeight(100); WindowManager.LayoutParams params = new WindowManager.LayoutParams(); params.type = WindowManager.LayoutParams.TYPE_PHONE; params.format = PixelFormat.RGBA_8888; params.gravity = Gravity.LEFT | Gravity.TOP; params.flags = WindowManager.LayoutParams.FLAG_NOT_TOUCH_MODAL | WindowManager.LayoutParams.FLAG_NOT_FOCUSABLE; params.width = 100; params.height = 100; params.x = 300; params.y = 300; windowManager.addView(button, params); } }
MainActivity中使用ButterKnife實例化四個Button,並設置觸摸事件監聽器:
public class MainActivity extends AppCompatActivity { @Bind(R.id.start) Button start; @Bind(R.id.stop) Button stop; @Bind(R.id.bind) Button bind; @Bind(R.id.unbind) Button unbind; @Override protected void onCreate(Bundle savedInstanceState) { super.onCreate(savedInstanceState); setContentView(R.layout.activity_main); ButterKnife.bind(this); start.setOnClickListener(new View.OnClickListener() { @Override public void onClick(View v) { startService(new Intent(MainActivity.this,FlowWindowService.class)); } }); stop.setOnClickListener(new View.OnClickListener() { @Override public void onClick(View v) { stopService(new Intent(MainActivity.this,FlowWindowService.class)); } }); bind.setOnClickListener(new View.OnClickListener() { @Override public void onClick(View v) { bindService(new Intent(MainActivity.this,FlowWindowService.class),connectionService, Context.BIND_AUTO_CREATE); } }); unbind.setOnClickListener(new View.OnClickListener() { @Override public void onClick(View v) { unbindService(connectionService); } }); } ServiceConnection connectionService = new ServiceConnection() { @Override public void onServiceConnected(ComponentName name, IBinder service) { } @Override public void onServiceDisconnected(ComponentName name) { } };
@Override public void onDestroy() { super.onDestroy(); Log.d(TAG,"onDestroy"); windowManager.removeView(button); }這意味著之前的代碼需要略作修改,button和windowManager都必須是類中定義的,而不是方法中定義的。
private static final int REQUEST_PERMISSION_CODE = 1; private void requestCameraPermission() { requestPermissions(new String[]{Manifest.permission.SYSTEM_ALERT_WINDOW}, REQUEST_PERMISSION_CAMERA_CODE); } @Override public void onRequestPermissionsResult(int requestCode, String[] permissions, int[] grantResults) { super.onRequestPermissionsResult(requestCode, permissions, grantResults); if (requestCode == REQUEST_PERMISSION_CODE) { int grantResult = grantResults[0]; boolean granted = grantResult == PackageManager.PERMISSION_GRANTED; Log.i(TAG, "onRequestPermissionsResult granted=" + granted); } }使用requestPermisson方法申請SYSTEM_ALERT_WINDOW權限,REQUEST_PERMISSON_CODE是一個整數,用來表示這次請求,它的值隨意。requestPermissions會導致onRequestPermissionsResult方法被回調,在這個方法中我們就可以知道我們是不是申請到了權限。最後,在MainActivity的onCreate方法中申請權限即可。
protected void onCreate(Bundle savedInstanceState) { super.onCreate(savedInstanceState); setContentView(R.layout.activity_main); ButterKnife.bind(this); requestPermission();如果權限申請失敗,很有可能是應用程序的權限太低,嘗試一下用系統簽名文件給它簽名,然後就OK了。另外,在Android的模擬器上是可以直接申請權限成功的。
button.setOnClickListener(new View.OnClickListener() { int count = 0; @Override public void onClick(View v) { if((count++)%2==0){ button.setBackgroundColor(Color.GREEN); }else { button.setBackgroundColor(Color.RED); } } });
Handler myHandler = new Handler(); Runnable runnable = new Runnable() { boolean direct = true; @Override public void run() { Log.v(TAG,"params.x: "+params.x); if(direct){ params.x+=10; if(params.x>800){ direct = false; } }else { params.x-=10; if(params.x<100){ direct = true; } } windowManager.updateViewLayout(button,params); if(!button.isAttachedToWindow()){ Log.v(TAG,"not attach to window"); }else{ myHandler.postDelayed(this,50); } } }; public void moveFlowButton(){ Log.v(TAG,"moveFlowButton"); myHandler.postDelayed(runnable,500); }
Process: com.konka.flowwindowtest, PID: 19478 java.lang.IllegalArgumentException: View=android.widget.Button{2553221 VFED..C.. ......I. 0,0-200,200} not attached to window manager at android.view.WindowManagerGlobal.findViewLocked(WindowManagerGlobal.java:456) at android.view.WindowManagerGlobal.updateViewLayout(WindowManagerGlobal.java:368) at android.view.WindowManagerImpl.updateViewLayout(WindowManagerImpl.java:99) at com.konka.flowwindowtest.FlowWindowService$1.run(FlowWindowService.java:89) at android.os.Handler.handleCallback(Handler.java:751) at android.os.Handler.dispatchMessage(Handler.java:95) at android.os.Looper.loop(Looper.java:154) at android.app.ActivityThread.main(ActivityThread.java:5969) at java.lang.reflect.Method.invoke(Native Method) at com.android.internal.os.ZygoteInit$MethodAndArgsCaller.run(ZygoteInit.java:801) at com.android.internal.os.ZygoteInit.main(ZygoteInit.java:691)這個問題應該是Service已經銷毀了,但是button還想要更新位置造成的,所以應該在銷毀Service前先取消handler更新button的動畫。 首先定義一個線程退出標志:
Boolean destoryStatus = false;在onDestory中是它為true即可:
synchronized (this){ destoryStatus = true; }run方法如下:
Runnable runnable = new Runnable() { boolean direct = true; @Override public void run() { if(!destoryStatus){ Log.v(TAG,"params.x: "+params.x); if(direct){ params.x+=10; if(params.x>800){ direct = false; } }else { params.x-=10; if(params.x<100){ direct = true; } } windowManager.updateViewLayout(button,params); myHandler.postDelayed(this,50); } } };這樣就不會有這個問題了。
