Android 中圖可以用到的圖片處理類 BitmapUtils

編輯:關於Android編程

Android在實際開發中很多時候都要對圖片進行一定的處理,這裡總結的BitmapUtils 類包括一下幾個功能:

1.Android圖片倒影,

2.Android圖片模糊處理,

3.Android圖片圓角處理,

4.圖片沿著y軸旋轉一定角度,

5.Android給圖片添加邊框。


接下來就直接上代碼了,代碼中有一定的解釋。直接哪來用就可以了。

/*
 * @Title: BitmapUtils.java
 * @Copyright: Corporation. Ltd. Copyright 1998-2018, All rights reserved
 * @Description: TODO<請描述此文件是做什麼的>
 * @author: xjp
 * @data: 2014年9月18日 上午10:10:30
 * @version: V1.0
 */
package com.mktech.bitmaputils;

import android.annotation.SuppressLint;
import android.annotation.TargetApi;
import android.content.Context;
import android.graphics.Bitmap;
import android.graphics.BitmapShader;
import android.graphics.Camera;
import android.graphics.Canvas;
import android.graphics.LinearGradient;
import android.graphics.Matrix;
import android.graphics.Paint;
import android.graphics.PorterDuffXfermode;
import android.graphics.Bitmap.Config;
import android.graphics.Rect;
import android.graphics.RectF;
import android.graphics.Shader;
import android.graphics.Shader.TileMode;
import android.os.Build;
import android.renderscript.Allocation;
import android.renderscript.Element;
import android.renderscript.RenderScript;
import android.renderscript.ScriptIntrinsicBlur;
import android.util.Log;

/**
 * TODO<請描述這個類是干什麼的>
 *
 * @author xjp
 * @data: 2014年9月18日 上午10:10:30
 * @version: V1.0
 */
public class BitmapUtils {

	private static final String TAG = "BitmapUtils";

	/**
	 *
	 * TODO<創建倒影圖片>
	 * @throw
	 * @return Bitmap
	 * @param srcBitmap 源圖片的bitmap
	 * @param reflectionHeight 圖片倒影的高度
	 */
	public static Bitmap createReflectedBitmap(Bitmap srcBitmap,int reflectionHeight) {

		if (null == srcBitmap) {
			Log.e(TAG, "the srcBitmap is null");
			return null;
		}

		// The gap between the reflection bitmap and original bitmap.
		final int REFLECTION_GAP = 0;

		int srcWidth = srcBitmap.getWidth();
		int srcHeight = srcBitmap.getHeight();

		if (0 == srcWidth || srcHeight == 0) {
			Log.e(TAG, "the srcBitmap is null");
			return null;
		}

		// The matrix
		Matrix matrix = new Matrix();
		matrix.preScale(1, -1);

		try {

			// The reflection bitmap, width is same with original's, height is
			// half of original's.
			Bitmap reflectionBitmap = Bitmap.createBitmap(srcBitmap, 0, srcHeight - reflectionHeight,
					srcWidth, reflectionHeight, matrix, false);

			if (null == reflectionBitmap) {
				Log.e(TAG, "Create the reflectionBitmap is failed");
				return null;
			}

			// Create the bitmap which contains original and reflection bitmap.
			Bitmap bitmapWithReflection = Bitmap.createBitmap(srcWidth, srcHeight + reflectionHeight,
					Bitmap.Config.ARGB_8888);

			if (null == bitmapWithReflection) {
				return null;
			}

			// Prepare the canvas to draw stuff.
			Canvas canvas = new Canvas(bitmapWithReflection);

			// Draw the original bitmap.
			canvas.drawBitmap(srcBitmap, 0, 0, null);

			// Draw the reflection bitmap.
			canvas.drawBitmap(reflectionBitmap, 0, srcHeight + REFLECTION_GAP,
					null);

			Paint paint = new Paint();
			paint.setAntiAlias(true);
			LinearGradient shader = new LinearGradient(0, srcHeight, 0,
					bitmapWithReflection.getHeight() + REFLECTION_GAP,
					0x70FFFFFF, 0x00FFFFFF, TileMode.MIRROR);
			paint.setShader(shader);
			paint.setXfermode(new PorterDuffXfermode(
					android.graphics.PorterDuff.Mode.DST_IN));

			canvas.save();
			// Draw the linear shader.
			canvas.drawRect(0, srcHeight, srcWidth,
					bitmapWithReflection.getHeight() + REFLECTION_GAP, paint);
			if (reflectionBitmap != null && !reflectionBitmap.isRecycled()){
				reflectionBitmap.recycle();
				reflectionBitmap = null;
			}

			canvas.restore();

			return bitmapWithReflection;
		} catch (Exception e) {
			e.printStackTrace();
		}
		Log.e(TAG, "Create the reflectionBitmap is failed");
		return null;
	}

	/**
	 *
	 * TODO<圖片圓角處理>
	 * @throw
	 * @return Bitmap
	 * @param srcBitmap 源圖片的bitmap
	 * @param ret 圓角的度數
	 */
    public static Bitmap getRoundImage(Bitmap srcBitmap, float ret) {

    		if(null == srcBitmap){
    			Log.e(TAG, "the srcBitmap is null");
    			return null;
    		}

            int bitWidth = srcBitmap.getWidth();
            int bitHight = srcBitmap.getHeight();

            BitmapShader bitmapShader = new BitmapShader(srcBitmap,
                    Shader.TileMode.CLAMP, Shader.TileMode.CLAMP);
            Paint paint = new Paint();
            paint.setAntiAlias(true);
            paint.setShader(bitmapShader);

            RectF rectf = new RectF(0, 0, bitWidth, bitHight);

            Bitmap outBitmap = Bitmap.createBitmap(bitWidth, bitHight,
                    Config.ARGB_8888);
            Canvas canvas = new Canvas(outBitmap);
            canvas.drawRoundRect(rectf, ret, ret, paint);
            canvas.save();
            canvas.restore();

            return outBitmap;
        }


    /**
     *
     * TODO<圖片沿著Y軸旋轉一定角度>
     * @throw
     * @return Bitmap
     * @param srcBitmap 源圖片的bitmap
     * @param reflectionHeight 圖片倒影的高度
     * @param rotate 圖片旋轉的角度
     */
    public static Bitmap skewImage(Bitmap srcBitmap, float rotate, int reflectionHeight) {

    	if(null == srcBitmap){
			Log.e(TAG, "the srcBitmap is null");
			return null;
		}

		Bitmap reflecteBitmap = createReflectedBitmap(srcBitmap, reflectionHeight);

		if (null == reflecteBitmap){
			Log.e(TAG, "failed to createReflectedBitmap");
			return null;
		}

		int wBitmap = reflecteBitmap.getWidth();
		int hBitmap = reflecteBitmap.getHeight();
		float scaleWidth = ((float) 180) / wBitmap;
		float scaleHeight = ((float) 270) / hBitmap;
		Matrix matrix = new Matrix();
		matrix.postScale(scaleWidth, scaleHeight);
		reflecteBitmap = Bitmap.createBitmap(reflecteBitmap, 0, 0, wBitmap, hBitmap, matrix,
				true);
		Camera localCamera = new Camera();
		localCamera.save();
		Matrix localMatrix = new Matrix();
		localCamera.rotateY(rotate);
		localCamera.getMatrix(localMatrix);
		localCamera.restore();
		localMatrix.preTranslate(-reflecteBitmap.getWidth() >> 1,
				-reflecteBitmap.getHeight() >> 1);
		Bitmap localBitmap2 = Bitmap.createBitmap(reflecteBitmap, 0, 0,
				reflecteBitmap.getWidth(), reflecteBitmap.getHeight(), localMatrix,
				true);
		Bitmap localBitmap3 = Bitmap.createBitmap(localBitmap2.getWidth(),
				localBitmap2.getHeight(), Bitmap.Config.ARGB_8888);
		Canvas localCanvas = new Canvas(localBitmap3);
		Paint localPaint = new Paint();
		localPaint.setAntiAlias(true);
		localPaint.setFilterBitmap(true);
		localCanvas.drawBitmap(localBitmap2, 0.0F, 0.0F, localPaint);
		if (null != reflecteBitmap && !reflecteBitmap.isRecycled()) {
			reflecteBitmap.recycle();
			reflecteBitmap = null;
		}
		if (null != localBitmap2 && !localBitmap2.isRecycled()) {
			localBitmap2.recycle();
			localBitmap2 = null;
		}
		localCanvas.save();
		localCanvas.restore();
		return localBitmap3;
	}


    /**
     *
     * TODO<圖片模糊化處理>
     * @throw
     * @return Bitmap
     * @param bitmap 源圖片
     * @param radius The radius of the blur Supported range 0 < radius <= 25
     * @param context 上下文
     */
    @TargetApi(Build.VERSION_CODES.JELLY_BEAN_MR1)
	@SuppressLint("NewApi")
	public static Bitmap blurBitmap(Bitmap bitmap,float radius,Context context){

        //Let's create an empty bitmap with the same size of the bitmap we want to blur
        Bitmap outBitmap = Bitmap.createBitmap(bitmap.getWidth(), bitmap.getHeight(), Config.ARGB_8888);

        //Instantiate a new Renderscript
        RenderScript rs = RenderScript.create(context);

        //Create an Intrinsic Blur Script using the Renderscript
        ScriptIntrinsicBlur blurScript = ScriptIntrinsicBlur.create(rs, Element.U8_4(rs));

        //Create the Allocations (in/out) with the Renderscript and the in/out bitmaps
        Allocation allIn = Allocation.createFromBitmap(rs, bitmap);
        Allocation allOut = Allocation.createFromBitmap(rs, outBitmap);

        //Set the radius of the blur
        if(radius > 25){
        	radius = 25.0f;
        }else if (radius <= 0){
        	radius = 1.0f;
        }
        blurScript.setRadius(radius);

        //Perform the Renderscript
        blurScript.setInput(allIn);
        blurScript.forEach(allOut);

        //Copy the final bitmap created by the out Allocation to the outBitmap
        allOut.copyTo(outBitmap);

        //recycle the original bitmap
        bitmap.recycle();
        bitmap = null;
        //After finishing everything, we destroy the Renderscript.
        rs.destroy();

        return outBitmap;


    }


    /**
     * TODO<給圖片添加指定顏色的邊框>
     * @param srcBitmap 原圖片
     * @param borderWidth 邊框寬度
     * @param color 邊框的顏色值
     * @return
     */
    public static Bitmap addFrameBitmap(Bitmap srcBitmap,int borderWidth,int color)
    {
    	if (srcBitmap == null){
    		Log.e(TAG, "the srcBitmap or borderBitmap is null");
			return null;
    	}

    	int newWidth = srcBitmap.getWidth() + borderWidth ;
    	int newHeight = srcBitmap.getHeight() + borderWidth ;

    	Bitmap outBitmap = Bitmap.createBitmap(newWidth, newHeight, Config.ARGB_8888);

    	Canvas canvas = new Canvas(outBitmap);

    	Rect rec = canvas.getClipBounds();
        rec.bottom--;
        rec.right--;
        Paint paint = new Paint();
        //設置邊框顏色
        paint.setColor(color);
        paint.setStyle(Paint.Style.STROKE);
        //設置邊框寬度
        paint.setStrokeWidth(borderWidth);
        canvas.drawRect(rec, paint);

    	canvas.drawBitmap(srcBitmap, borderWidth/2, borderWidth/2, null);
    	canvas.save(Canvas.ALL_SAVE_FLAG);
    	canvas.restore();
    	if (srcBitmap !=null && !srcBitmap.isRecycled()){
    		srcBitmap.recycle();
    		srcBitmap = null;
    	}

    	return outBitmap;
    }

}
以上代碼經驗證可以直接使用。

分享。

完結。
